Specifications

Description

The V-100, 200 and 300 series from Thermo King comprise two-piece split units designed for fresh, frozen and deep frozen applications on small trucks and vans. The road compressor is powered by the vehicle’s engine. In models with electric stand-by, the second one is powered by an electric motor. The V-200 and V-300 MAX TC can manage two evaporators to provide temperature control for two compartments. Models with hot gas heating are also available.

System components

• Condenser:
  • Small condenser section: V-100 series with and without electric stand-by, and V-200 and V-300 series without electric stand-by
  • Larger condenser section: V-200 and V-300 series with electric stand-by
• Ultra slim evaporator:
  • ES 100 (V-100 series and V-200 MAX TC)
  • ES 150 (V-300 MAX TC)
  • ES 200 (V-200 series with the exception of bi-temperature models)
  • ES 300 (V-300 series with the exception of bi-temperature models)
• Engine driven compressor
• Installation kit
• In-cab control box
• Modules:
  • MH (heating) module for 30/50 models
  • MTC module for bi-temperature models
  • MTCH module for bi-temperature and heating models
  • Vehicle drive kit (on request)

Standard features

• Jet Lube™ compressor lubrication
• Jet Cool™ compressor injection cooling (MAX models)
• In-cab controls with digital LED thermometer
• Automatic hot gas defrost
• Electric thermostat

Refrigerant

• V-100: 1.0 kg of HFC R-134a
• V-100 MAX: 1.0 kg of HFC R-404A
• V-200: 1.4 kg of HFC R-134a
• V-200 MAX: 1.25 kg of HFC R-404A
• V-300: 1.75 kg of HFC R-134a
• V-300 MAX: 1.75 kg of HFC R-404AChlorine: Zero

Compressor (engine driven)

V-100 series

• Number of cylinders: 6
• Displacement: 82 cm3(5 cu. in.)
• Maximum recommended speed: 3,000 rpm
• Jet Lube™ and Jet Cool™ (on MAX units) compressor lubrication and cooling systems

V-200 series

• Number of cylinders: 6
• Displacement: 131 cm3(8 cu. in.)
• Maximum recommended speed: 3,000 rpm
• Jet Lube™ and Jet Cool™ (on MAX units) compressor

V-300 series

• Number of cylinders: 6
• Displacement: 146.7 cm3 (8.95 cu. in.)
• Maximum recommended speed: 3,000 rpm
• Jet Lube™ and Jet Cool™ (on MAX units) compressor lubrication and cooling systems

Defrost

Automatic hot gas defrost
